Entry-level Shimano drop-bar gearing that shifts like the good stuff

The CUES U3000 1x9 drop-bar groupset brings Shimano's DUAL CONTROL LEVER ergonomics and LINKGLIDE durability to a single-chainring road, gravel or commuter build with cable-actuated disc brakes. LINKGLIDE cassettes and chains are built for long service life and clean shifts under load, which is why CUES has replaced Shimano's older entry ranges.

Kit includes

  • ST-U3030-9R right shift/brake lever (9-speed, mechanical disc)
  • BL-U3030-L left brake lever (mechanical disc)
  • RD-U3020 rear derailleur, SGS cage
  • CS-LG400-9 LINKGLIDE 9-speed cassette, 11-36T (the ratio RD-U3020 is designed for)
  • CN-LG500 LINKGLIDE chain, 138 links

Options

  • FC-U4000-1 crankset, your choice of 170 or 175 mm and 30, 32, 40 or 42T (optional: add it unless your bike is an e-bike or keeps its crank)
  • BR-RS305 flat-mount mechanical disc calipers, front and rear
  • RT-CL700 Center Lock rotors (choose size)
  • BB-UN300 square-taper bottom bracket, 68 x 123 mm

The crank, bottom bracket, brakes and rotors are optional extras that start at 0, so e-bikes and bikes keeping their own parts are not charged for them. Every other part can be deselected if you already have it. Levers take NEW SUPER SLR road calipers and 23.8 to 24.2 mm drop bars. The cassette fits a standard HG freehub body; the crank is square taper.

Tune Cycles supplies and fits Shimano CUES across Sydney. Choose your options above; if you are unsure what your frame takes, ask us before you order.

Every part in this kit is covered by Shimano's standard manufacturer warranty against defects in materials and workmanship. Wear from normal use, incorrect installation or crash damage is not covered. For any warranty claim or support, return the part to Tune Cycles and we will handle it with Shimano.

  • ST-U3030-9R right DUAL CONTROL LEVER: 9-speed rear shifting and cable-actuated disc braking for drop bars
  • BL-U3030-L left brake lever, cable-actuated disc
  • RD-U3020-SGS rear derailleur, made for a 36T low sprocket with 41T total capacity
  • CS-LG400-9 LINKGLIDE 9-speed cassette, 11-36T, on a standard HG freehub body
  • CN-LG500 LINKGLIDE chain, 138 links, with quick link
  • Optional extras that start at 0: FC-U4000-1 square-taper crankset in 170 or 175 mm with a 30, 32, 40 or 42T ring; BR-RS305 flat-mount cable-actuated disc calipers, front and rear; RT-CL700 Center Lock rotors in 140, 160, 180 or 203 mm, up to two; BB-UN300 square-taper bottom bracket, 68 x 123 mm
  • LINKGLIDE cassette and chain: shift cleanly under load and outlast a conventional drivetrain, which suits e-bikes and hard-working commuters
  • Editable kit: deselect any part you already have and add only the extras your bike needs; the price follows the parts you keep
Brand Shimano
Series Shimano CUES U3000 (LINKGLIDE)
Drivetrain 1x9-speed
Handlebar Drop bar, 23.8-24.2 mm lever clamp
Brakes Cable-actuated disc levers (NEW SUPER SLR); BR-RS305 flat-mount calipers optional
Right lever ST-U3030-9R, 9-speed
Left lever BL-U3030-L, brake only
Rear derailleur RD-U3020-SGS, 36T low sprocket, 41T capacity
Cassette CS-LG400-9, 11-36T LINKGLIDE
Chain CN-LG500, 138 links, quick link
Crankset (optional) FC-U4000-1, 170 or 175 mm, 30 / 32 / 40 / 42T, square taper
Bottom bracket (optional) BB-UN300, 68 x 123 mm square taper
Brakes (optional) BR-RS305 flat mount, front and rear
Rotors (optional) RT-CL700 Center Lock, 140 / 160 / 180 / 203 mm
Freehub Shimano HG spline
SKU SHM-U3000-1x9-DROP-GROUP
