The hard-wearing 11-speed drivetrain for e-MTBs

Deore XT M8130 is Shimano's LINKGLIDE drivetrain, built for the torque of a mid-drive motor. LINKGLIDE sprockets are taller and thicker than HYPERGLIDE, the chain sits deeper in each gear, and shifts land cleanly under full power. Shimano rates the cassette at up to three times the life of a conventional one. This kit is the four parts that make up that drivetrain, sold together so they match.

Kit includes

  • SL-M8130 RAPIDFIRE PLUS right shifter, 11-speed, in a band-clamp or I-SPEC EV mount
  • RD-M8130-SGS SHADOW RD+ rear derailleur, 11-speed, long cage, made for a 50T low sprocket
  • CS-LG700-11 LINKGLIDE cassette, 11-50T, for a standard Shimano HG freehub body
  • CN-LG500 LINKGLIDE chain, 138 links, with quick link

What is not in the box

No crank and no brakes. E-bikes use the motor's own crank arms, so a crank would only add cost; if your bike needs one, ask us before you order. The RD-M8130-SGS is made for the 11-50T cassette only, so the smaller 11-45T LINKGLIDE cassette is not offered here. Every part can be deselected if you already have it, and the price follows the parts you keep.

Fits

Flat-bar bikes with a Shimano HG-spline freehub. LINKGLIDE parts are designed to work only with each other: the shifter, derailleur, cassette and chain here are all LINKGLIDE 11-speed and do not mix with 11-speed HYPERGLIDE or 12-speed HYPERGLIDE+ components.

Tune Cycles supplies and fits Shimano across Sydney as Australia's only Authorised Mobile Shimano Service Centre. Fitting is quoted separately when you book.

Every part in this kit is covered by Shimano's standard manufacturer warranty against defects in materials and workmanship. Wear from normal use, incorrect installation or crash damage is not covered. For any warranty claim or support, return the part to Tune Cycles and we will handle it with Shimano.

  • SL-M8130 RAPIDFIRE PLUS right shifter, 11-speed, choose a band clamp or I-SPEC EV mount
  • RD-M8130-SGS SHADOW RD+ rear derailleur, 11-speed long cage, made for a 50T low sprocket with 39T total capacity
  • CS-LG700-11 LINKGLIDE 11-speed cassette, 11-50T, on a standard HG freehub body
  • CN-LG500 LINKGLIDE chain, 138 links, with quick link
  • No crank or brakes: an e-bike drivetrain kit that fits around the motor's own crank arms
  • LINKGLIDE cassette and chain: shift cleanly under load and outlast a conventional drivetrain, which suits e-bikes and hard-working commuters
  • Editable kit: deselect any part you already have; the price follows the parts you keep
Brand Shimano
Series Shimano Deore XT M8130 (LINKGLIDE)
Drivetrain 1x11-speed
Intended use E-MTB and e-bike, trail
Handlebar Flat bar
Shifter SL-M8130 RAPIDFIRE PLUS, 11-speed, band clamp or I-SPEC EV
Rear derailleur RD-M8130-SGS SHADOW RD+, 11-speed, long cage, 50T low sprocket, 39T capacity
Cassette CS-LG700-11 LINKGLIDE, 11-50T
Chain CN-LG500, 138 links, quick link
Crankset Not included
Brakes Not included
Freehub Shimano HG spline
SKU SHM-M8130-GROUP
Barcode # 2000000001470
Brand Shimano
