A square-taper 1x mountain bike crankset with a 32T steel narrow-wide ring on a 104 BCD spider, a simple upgrade or replacement for bikes with a JIS square-taper bottom bracket.

Highlights

  • 32T steel narrow-wide chainring on 104 BCD
  • 50mm chainline
  • JIS square taper, 113mm spindle (Prowheel spec)
  • Forged AL-6061-T6 arms, sand black
  • Rated by Prowheel for 9, 10 and 11-speed
  • 165mm, 170mm or 175mm

Room to change gearing

The 104 BCD spider lets you change ring size later, and Prowheel offers the FD04S ring from 32T to 40T.

Compatibility & fit

This is the non-Boost version with a 50mm chainline. Fits a JIS square-taper bottom bracket; Prowheel specifies a 113mm spindle. No bottom bracket is included. Prowheel rates this crank for 9, 10 and 11-speed drivetrains. Fitting is a separate workshop service and isn't included. Our Marrickville workshop can fit the crankset and bottom bracket and check your chainline.

Sizes & options

LengthChainringVersion
165mm32TNon-Boost
170mm32TNon-Boost
175mm32TNon-Boost
Covered against manufacturing defects under Prowheel's warranty. Normal wear, crash damage and incorrect fitting are not manufacturing defects. For warranty support, return the product to Tune Cycles and we'll manage the claim with KWT Imports, Prowheel's Australian distributor.
  • 32T steel narrow-wide ring, 104 BCD
  • 50mm chainline
  • JIS square taper, 113mm spindle
  • Forged AL-6061-T6 arms
  • 9, 10 and 11-speed
Crank length165mm, 170mm or 175mm
Chainring32T, steel, narrow-wide, black
BCD104mm
Chainline50mm (non-Boost)
Speed9 / 10 / 11-speed
Crank materialForged AL-6061-T6 aluminium
Crank finishSand black
Q-factor / I-factor175 / 145mm
Bottom bracketJIS square taper, 113mm spindle (not included)
SKU KWT-P-PRW-FD04STAPER-NB
Brand PROWHEEL
Shipping Weight 0.9000kg
Shipping Width 0.250m
Shipping Height 0.100m
Shipping Length 0.400m
