FUNN Fantom AM40 Front Wheel – 35mm Internal, 32H, 6-Bolt, Boost 15 x 110mm – 27.5 Inch
SKU code: KWT-FN-FW2740BST
$369.95
A tough, light front wheel for trail and enduro. The Fantom AM40 pairs FUNN's welded Fantom rim, at 35mm internal width, with a Fantom front hub built to be simple, quiet and long-lasting.
Highlights
- Fantom AM40 rim: 35mm internal, 40mm external
- Welded joint, sandblasted black anodised finish
- 32-hole Fantom front hub with sealed cartridge bearings
- Boost 15 x 110mm thru-axle, 6-bolt disc mount
- Tubeless-ready, supplied with tubeless rim tape and valve
- 27.5in or 29in
The rim
The 35mm internal width spreads a big tyre into its full profile for maximum grip and stability, for trail and enduro riders running wide tyres. The welded joint keeps the rim strong at the seam without adding weight.
Ready for tubeless
The wheel comes supplied with tubeless rim tape and a valve, so all you need to add is a tubeless tyre and sealant.
Tyres, rotors and sealant are not included. Our workshop can fit tyres, set up tubeless, true the wheel and service the hub as separate services.
Compatibility & fit
- Fork: Boost 15 x 110mm thru-axle
- Disc brake: 6-bolt rotor (not included)
- Wheel size: 27.5in or 29in; choose the size your frame and fork are built for
Sizes & options
| Diameter |
|---|
| 27.5 Inch |
| 29 Inch |
This FUNN product is covered against defects in materials and workmanship. Normal wear, crash or impact damage, and damage from incorrect fitting or misuse are not manufacturing defects, and your rights under Australian Consumer Law are not affected. For warranty support, return the product to Tune Cycles and we'll manage the claim with KWT Imports, FUNN's Australian distributor.
- Fantom AM40 front wheel, 35mm internal
- Welded alloy rim, 32H
- Boost 15 x 110mm, 6-bolt
- Tubeless-ready, tape and valve supplied
- 27.5in or 29in
| Rim | Fantom AM40 |
|---|---|
| Internal / external width | 35mm / 40mm |
| Rim construction | Welded AL6066, welded joint, sandblasted black anodised |
| Spoke count | 32H |
| Hub | Fantom front, sealed cartridge bearings |
| Axle | Boost 15 x 110mm thru-axle |
| Disc mount | 6-bolt |
| Tubeless | Ready; tubeless rim tape and valve supplied |
| Wheel sizes | 27.5in, 29in |
| SKU | KWT-P-FN-FANTOM-FWAM40 |
| Brand | FUNN |
| Shipping Weight | 1.4000kg |
| Shipping Width | 0.700m |
| Shipping Height | 0.120m |
| Shipping Length | 0.700m |
