Mountain bike cleats have traditionally been mild steel or brass: heavy, and often quick to wear. SILCA 3D prints its cleats in 6Al/4V titanium with an internal gyroid lattice that keeps them stiff and strong while cutting the weight of a cleat set in half.

Highlights

  • 3D-printed 6Al/4V titanium with gyroid lattice structure
  • About half the weight of a standard cleat set
  • Titanium hardware included
  • 4x the life expectancy of brass
  • 3D printed in Indianapolis

Lighter where you feel it

Saving 25-30g per cleat set is significant over time, and it's most noticeable in cyclocross and any race where you're running with the bike.

Fitting notes

SILCA says torque up to 10Nm is acceptable (the packaging states 6Nm) and may be needed on very hard carbon soles. Grease the threads and under the screw heads, and re-tighten after 24 hours or your first ride, as the cleat can bed into the sole.

Compatibility & fit

Choose the option that matches your pedal system: Shimano SPD, Crank Brothers or TIME ATAC. Each option carries that system's float and release (see options).

Options

Pedal systemWeightSaving vs stockFloatRelease
Shimano SPD24g30g4°Single release
Crank Brothers22g24g6°15°
TIME ATAC22g26g5°10°
Covered by the SILCA Limited Warranty: guaranteed against defects in materials and manufacturing workmanship for 2 years, with wear and tear under regular use covered for 1 year (6 months in commercial environments). For warranty support, return the product to Tune Cycles and we'll manage the claim with SILCA's Australian distributor.
  • 3D-printed 6Al/4V titanium
  • Gyroid lattice for strength at low weight
  • Around half the weight of standard cleats
  • Titanium hardware included
  • 4x life expectancy of brass
Material3D-printed 6Al/4V titanium
Hardware6Al/4V titanium, included
Maximum torqueUp to 10Nm per SILCA
Made inIndianapolis, USA
OptionsShimano SPD (24g, 4° float), Crank Brothers (22g, 6° float), TIME ATAC (22g, 5° float)
SKU ECH-P-SI-3DP-CLEAT
Brand SILCA
