Confident, controllable stopping power for enduro and demanding trail riding. This Shimano Deore XT brake pairs the four-piston BR-M8220 caliper with the refined BL-M8200 lever, so you get strong, consistent bite and the modulation to manage it lap after lap.

Highlights

  • Four-piston post-mount caliper built for enduro-level power and heat management
  • Refreshed SERVO WAVE lever delivers an early, controllable bite with a consistent feel
  • Tool-free reach adjust and free-stroke adjust to dial in lever position and engagement
  • Low-viscosity Shimano mineral oil for a stable bite point across a wide temperature range
  • One-way bleed system makes servicing cleaner and simpler
  • Supplied with finned resin pads for quiet, progressive braking

Power and control

The BR-M8220 caliper uses a four-piston, dual-diameter design and updated seals for strong, repeatable stopping with steady deceleration. Matched to the SERVO WAVE lever, the power curve builds smoothly through the lever pull rather than grabbing all at once, giving you control on steep, technical descents.

Set up to suit you

The alloy BL-M8200 lever offers tool-free reach adjust and free-stroke adjust so you can tune lever position and engagement without tools. It is I-SPEC EV compatible, letting you mount a matching shifter or dropper remote directly to the brake clamp for a tidy cockpit.

Consistent in all conditions

Low-viscosity Shimano mineral oil keeps the bite point stable as temperatures change, while the one-way bleed system and revised bleed port make maintenance tidier. Finned pads help shed heat on long descents.

Compatibility & fit

This is the right-hand lever, which in the standard Australian setup operates the front brake. It is a post-mount caliper supplied without an adapter, so select the correct mount adapter for your fork and rotor size. The lever ships with a 1000 mm SM-BH90-SBM hose suited to a front installation. Supplied with finned resin pads; metal pads are also available separately. Rotor sold separately. Use only Shimano mineral oil – never DOT fluid.

Shimano components are covered by a manufacturer's warranty against defects in materials and workmanship. The warranty does not cover normal wear (including brake pads), damage from crashes, improper installation or servicing, or use of non-Shimano fluid (always use Shimano mineral oil, never DOT).

For warranty support, return the item to Tune Cycles and we'll manage the claim for you.

This warranty is in addition to your rights under the Australian Consumer Law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.

  • Four-piston BR-M8220 post-mount caliper for enduro-level stopping power
  • Refreshed SERVO WAVE for an early, controllable bite and smooth power delivery
  • Alloy BL-M8200 lever with tool-free reach adjust and free-stroke adjust
  • I-SPEC EV compatible for direct shifter/remote mounting
  • Low-viscosity Shimano mineral oil for a stable bite point across temperatures
  • One-way bleed system with revised bleed port for cleaner servicing
  • Supplied with finned resin pads for quiet, progressive braking
  • 1000 mm SM-BH90-SBM hose, suited to a front installation
  • Right-hand lever (front brake in the standard Australian setup)
  • Black finish
BrandShimano
SeriesDeore XT
Lever modelBL-M8200
Caliper modelBR-M8220
TypeHydraulic disc brake
Pistons4-piston
Caliper mountPost mount
SideRight lever / front brake
SERVO WAVEYes
Reach adjustTool-free
Free-stroke adjustYes
Shifter mountI-SPEC EV compatible
Pads suppliedResin with fin
HoseSM-BH90-SBM, 1000 mm
FluidShimano low-viscosity mineral oil
BleedOne-way bleed system
AdapterNot included
RotorNot included
ColourBlack
SKU SHM-IM82201JRFXSA100
Barcode # 4550170309893
