The Atlas front wheel is made for the gnarliest downhill lines, rock gardens and big jumps. A tough 30mm 6069 alloy rim with a dent and flat resistant bead is laced to the Vault hub for 20x110mm forks.

Highlights

• 20x110mm front axle, Boost or non-Boost
• 6069 alloy rim, 30mm internal and 34mm external width, tubeless ready
• Dent and flat resistant bead design
• Vault hub with a stiff oversized shell and wide bearing stance
• 28 double-butted straight-pull spokes (2.0/1.8/2.0), 3-cross
• Backed by Race Face's Lifetime Warranty, crashes included

Taking the hits

Atlas is built from 6069 alloy with a dent and flat resistant bead design to stand up to gravity-fed mayhem. Offset spoke beds are laced with burly double-butted straight-pull spokes for stiffness and hassle-free riding.

20x110 Boost or non-Boost

Race Face makes the Atlas front in 20x110mm Boost and, in 27.5in, 20x110mm non-Boost. The 20x110 Boost wheels come with endcaps fitted for a 20mm axle and include 15mm conversion endcaps as spares.

Compatibility & fit

Check your fork's axle before you choose: 20x110mm Boost and 20x110mm non-Boost are different standards. The hub takes a 6-bolt disc rotor. This is a single front wheel; tyre and disc rotor aren't included. Fitting isn't included. Our Marrickville workshop can fit the wheel, set it up tubeless and move your rotor across as a separate service.

Sizes & options

Every option is a black 30mm Atlas front wheel on the Vault hub.
