FH-MT400-B

SHIMANO - Rear FREEHUB - CENTER LOCK - Disc Brake - 12-x148 mm E-THRU Axle - 8/9/10-speed - 11-speed MTB

With CENTER LOCK disc rotor mounting, the E-THRU FH-MT400-B freehub offers stiffer wheel rigidity, smooth rotation, and less drag.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • Stiffer wheel rigidity
  • 148 x 12 mm rear E-THRU
  • Quick and easy assembly
  • CENTER LOCK
  • MODEL NO: FH-MT400-B
  • ACERA M3000 Series
  • Color: Black
  • Brake type: CENTER LOCK disc brake
  • Axle fixing method: 12 mm E-THRU
  • Thru Axle (Length x Inner diameter: 148mm x 12mm
  • Bearing_Cone: CBN
  • Brake Type: CENTER LOCK disc brake
  • External serration disc brake rotor lock ring_without
  • Flange diameter Left/Right: 52.8mm/53.8mm
  • Flange distance: 63.4mm
  • Internal grease sleeve
  • Internal serration disc brake rotor lock ring without
  • O.L.D: 148mm
  • Offset: 6.65mm
  • P.C.D. left / right: 44mm/45mm
  • Quick engagement    X (more than 36 times/360 deg.)
  • Seal_Freehub body: Contact
  • Seal Hub: Labyrinth & Contact
  • Speeds: 8-10 speed, MTB 11-speed
  • Spoke holes: 28H
  • Spoke holes: 32H
  • Spoke holes: 36H
  • Internal grease sleeve
  • Spoke hole: 28H
  • Spoke hole: 32H
  • Spoke hole: 36H
  • Rear speeds: 8-10 speed, MTB 11-speed
  • Seal FREEHUB body: Contact
  • Seal Hub: Labyrinth & Contact
  • HG spline (Others)
  • Ratchet system type    Pawl ratchet
SKU SHM-Y3F898010
Barcode # 4550170516123
Brand Shimano
Shipping Weight 0.3000kg
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
