FH-M8110-B

SHIMANO DEORE XT - Rear FREEHUB - MICRO SPLINE - CENTER LOCK - Disc Brake - 148x12 mm E-THRU Axle - 12-speed

Compatible with 12-speed MICRO SPLINE cassettes.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • Faster acceleration amplifies riding excitement
  • Smaller spline diameter for 10T top gear by MICRO SPLINE
  • Simple setup and reliable trail performance
  • Easy disc brake rotor installation with spline mount and lock ring
  • CENTER LOCK
  • O.L.D.: 148 mm
  • MODEL NO: FH-M8110-B
  • DEORE XT M8100 Series
  • Series color
  • Average weight: 307g
  • CENTER LOCK disc brake type
  • Axle fixing method: 12 mm E-THRU
  • Thru Axle (Length x Inner diameter ; mm)_148 x 12
  • Bearing_Cone: CBN & Polish
  • Bearing_Cup: Polish
  • CENTER LOCK disc brake type
  • External serration disc brake rotor lock ring_without
  • Flange diameter Left/Right: 68.8/69.8mm
  • Flange distance: 62.16mm
  • Internal serration disc brake rotor lock ring_without
  • O.L.D.: 148mm
  • Offset: 6.6mm
  • P.C.D. left / right: 60/61mm
  • Quick engagement: X (max 7.0 deg.)
  • Seal_Freehub body: Contact
  • Seal_Hub: Labyrinth & Contact
  • Speeds: 12
  • Spoke holes_28H
  • Spoke holes_32H
  • Spoke holes_36H
  • 10 tooth cog compatible
  • O.L.D.: 148mm
  • Spoke hole_28H
  • Spoke hole_32H
  • Spoke hole_36H
  • Rear speeds: 12
  • Seal_FREEHUB body: Contact
  • Seal_Hub: Labyrinth & Contact
  • MICRO SPLINE
  • Ratchet system type: Direct engagement
SKU SHM-Y3G198010
Barcode # 4550170621650
Brand Shimano
Shipping Weight 0.3000kg
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
