FH-M525A

SHIMANO - Rear FREEHUB - 6-Bolt Disc Brake - Quick Release - 11-speed

For use with 6-bolt disc brake rotors and quick release dropouts, the SHIMANO FH-M525A rear hub is available in silver and black and compatible with 11-speed cassettes.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • 6-bolt disc rotor mount
  • Double contact sealing
  • Super polished bearing races
  • Ultra-smooth bearing race surfaces provide a precision low-friction rolling action
  • Light alloy quick release
  • Quick release lever and adjusting nut are made from light alloy
  • Cup & Cone Bearing
  • Color options: Black, Silver
  • MODEL NO: FH-M525A
  • SERIES: SHIMANO
  • Color: Black | Silver
  • Brake type: 6-bolt disc brake
  • Axle fixing method: Quick release
  • Bearing Cone: CBN
  • Brake Type: 6-bolt disc brake
  • Flange diameter Left/Right (mm)    70.6
  • Flange distance: 57.1(mm)
  • O.L.D: 135(mm)
  • Offset: 6.8(mm)
  • P.C.D. left / right: 61/61(mm)
  • QR Skewer Length 168mm
  • QR Skewer Length 173mm
  • QR lever Color: Black | Black
  • Seal Freehub body: Contact
  • Seal Hub: Labyrinth & Contact
  • Speeds: 8-10 speed, MTB 11-speed
  • Spoke holes 32H
  • Spoke holes 36H
  • HG spline (Others)
  • Ratchet system type: Pawl ratchet
SKU SHM-EFHM525ABZL
Barcode # 4524667691174
Brand Shimano
Shipping Weight 0.3000kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.220m
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
