A replacement flat-mount hydraulic caliper from Campagnolo's road disc brake system, 140mm. Powerful, modular braking from 22 mm pistons with a clean, drag-free release.

Highlights

  • 22 mm phenolic-resin pistons for braking force and thermal isolation
  • Pad return optimised: no friction when the lever is released
  • 0.4–0.8 mm pad clearance with no risk of accidental rub
  • Anti-vibration plate between pad and piston
  • Pads with wear indicators

Fitting

140 mm caliper; Campagnolo limits 140 mm rotors to riders up to 82 kg (90 kg rider + bike + accessories). Fitting it with 160 mm rotors, or at the front, uses Campagnolo's flat-mount adaptors.

Compatibility & fit

For Campagnolo mineral-oil hydraulic disc brake systems with standard flat mount. Campagnolo's pads, cylinder, screws and bolts are common to all its flat-mount calipers. Mineral oil only, never DOT fluid. Campagnolo's weight limits: 140 mm rotors for riders up to 82 kg (90 kg rider + bike + accessories); 160 mm rotors up to 109 kg (120 kg total).

Fitting, hose cutting and bleeding Campagnolo hydraulic brakes are separate workshop services and are not included in the price. Tune Cycles' workshop can set up and bleed your Campagnolo disc brakes.

Campagnolo guarantees its components for 3 years from the date of purchase against defects in materials and workmanship. Normal wear and tear, crash damage, misuse and incorrect installation are not covered. Campagnolo's disc brake manual also states that exceeding the rider/system weight limits for the rotor size voids the warranty; keep your proof of purchase. For warranty support, return the product to Tune Cycles and we'll manage the claim with Campagnolo's Australian distributor.
  • Standard flat mount
  • 22 mm phenolic-resin pistons
  • Drag-free pad return
  • Anti-vibration plate
  • Pads with wear indicators
MountStandard flat mount
Size140mm
Rotor140 mm (160 mm with adaptor)
Pistons22 mm phenolic resin
Pad clearance0.4–0.8 mm
FluidMineral oil
Claimed weight118 g (140 mm, one caliper, pads included)
SKU FES-DB-R141
Brand Campagnolo
Shipping Weight 0.2500kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.220m
