WH-RX05

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • MODEL NO: WH-RX05-FR
  • SHIMANO Series
  • Color: Black | White
  • Average weight: 958g F and 1142g R
  • Remarks    *The adapter is needed to use 10-speed CS
  • Spokes_Color: Black
  • Bike Type: Comfort
  • Axle_Length: 108mm F and 146mm R
  • Axle_Diameter: 10mm FR
  • Axle_Fixing method: QR
  • QR Skewer Length: 133mm F and 168mm | 173mm R
  • Quick release skewer length: 133mm
  • Bearing_Cone: CBN finish
  • Bearing_Cup: Polish
  • Brake Type: Disc brake
  • Disc mount_140 mm Disc brake rotor compatible
  • Disc mount_CENTER LOCK
  • Front/Rear: Yes
  • Grease holding function
  • O.L.D.: 100mm F and 135mm R
  • Rear speeds: 8 | 9 | 10
  • Reflector_AS: CATEYE RR-550-WUA SW
  • Reflector_DIN: CATEYE RR-317-WUA SW
  • Reflector_JIS/CPSC: CATEYE RR-550-WUW SW
  • Rim_Height: 24mm
  • Rim_Requires rim tape
  • Rim_Rim joint: Sleeved
  • Rim_Width: 224mm
  • Seal_Hub: Contact
  • Spokes_Number: 28
  • Tire_Recommended size: 25-622 - 38-622
  • Tire_Type: Clincher
  • Wheel Size: 622x17C

SKU SHM-EWHSPOKE3XC1
Barcode # 4524667504627
Brand Shimano
Shipping Weight 0.3000kg
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
