WH-MT66-R-29

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • SHIMANO engineered proprietary sealing tubeless system
  • 24.6mm wide rim profile (19C)
  • UST tubeless compatible
  • Quick, double pawl engagement FREEHUB optimizes traction
  • 2-cross laced tangent straight-laced spokes optimize torsional rigidity
  • E-THRU rear 12mm stiff axle improves cassette and rotor precision
  • E-THRU front 15mm stiff axle minimizes suspension distortion
  • CENTER LOCK is a quick, simple, lightweight, and effective rotor mounting system
  • Angular Contact Cup & Cone Bearings with labyrinth & contact high-quality sealing
  • MODEL NO: WH-MT66-R-29
  • SERIES: SHIMANO
  • Color: Black/White
  • Average weight: 1115g
  • Remarks: ** Exclusive rim tape***CP is available only for 9 & 10-speed
  • Spokes Straight pull
  • Quick engagement: X (32points/360°)
  • QR lever Color: Black
  • Bike Type: MTB
  • Axle Length: 146
  • Axle Diameter: 14
  • Axle Fixing method: QR
  • QR Skewer Length: 168mm, 173mm
  • Quick-release skewer length 168
  • Quick-release skewer length 173
  • Bearing_Cone: CBN
  • Brake Type: Center Lock Disc
  • Front/Rear: Rear
  • Grease holding function
  • O.L.D: 135
  • Rear speeds: 8
  • Reflector AS: CATEYE RR-550-WUA SW
  • Reflector DIN: CATEYE RR-317-WUA SW
  • Reflector JIS/CPSC: CATEYE RR-550-WUW SW
  • Rim Height: 19
  • Rim Requires rim tape: X**
  • Rim Rim joint: Welding
  • Rim Width: 246
  • Seal FREEHUB body: Contact
  • Seal Hub: Labyrinth & Contact
  • Spokes_Butted: 2.0-1.8-2.0
  • Spokes_Number: 28
  • Tire Recommended size: 29x1.50-2.25
  • Tire Type: UST/clincher
  • Wheel Size: 622x19C (29)
SKU SHM-EWHSPOKE3BB1
Barcode # 4524667934172
Brand Shimano
Shipping Weight 0.3000kg
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
