Built for long-distance and randonneuring riding, with mounts for a porteur or low-rider rack, internal dynamo routing and generous tyre clearance for all-road use.

Highlights

  • 1-1/8in straight steerer with integrated 45° crown race
  • 100×12mm thru-axle (included)
  • Flat mount disc brake, 140/160mm rotor compatible
  • Porteur or low-rider rack mounts, fender mounts, triple leg mounts (2.5kg max per leg)
  • Internal dynamo cable routing
  • 395g with uncut steerer (axle excluded)

Compatibility & fit

For a 1-1/8in straight head tube. 100×12mm thru-axle, included. Flat mount disc brake, rated to 140/160mm rotors. Clearance for 700 × 40c tyres without fenders, or 700 × 36c with fenders (depending on tyre/rim combination); 4mm minimum road clearance. The front crown mount is closed and isn't for accessories; use the dropout and leg mounts instead.

Ritchey covers this product for two years from the date of purchase against defects in materials and workmanship (the Ritchey International warranty, which covers Australia). Normal wear and tear isn't covered. For warranty support, return the product to Tune Cycles and we'll manage the claim with Ritchey's Australian distributor. This is in addition to your rights under the Australian Consumer Law, so keep your proof of purchase.
  • 1-1/8in straight steerer, integrated crown race
  • 100×12mm thru-axle included
  • Flat mount disc, 140/160mm rotor
  • Porteur/low-rider rack, fender and leg mounts (2.5kg max/leg)
  • Internal dynamo routing
  • 395g uncut, matte UD carbon
BrandRitchey
MaterialCarbon fibre
Steerer1-1/8in straight, integrated 45° crown race, 300mm
Axle-to-crown388mm
Rake/offset48mm
Crown diameter44mm
Axle100×12mm thru-axle (included)
Brake mountFlat mount disc, 140/160mm rotor
Tyre clearance700×40c (no fender) / 700×36c (with fender), 4mm minimum
MountsPorteur/low-rider rack, fender, leg mounts (2.5kg max/leg), internal dynamo routing
Weight395g (uncut steerer, axle excluded)
ColourMatte UD carbon
SKU DTW-RIG-34056117002
Barcode # 796941340892
Brand Ritchey
Shipping Weight 1.5000kg
