A steel gravel and adventure frameset built for loaded, mixed-terrain riding – triple-butted Ritchey Logic steel for a resilient, comfortable ride, paired with Ritchey's own carbon Adventure fork.

Highlights

  • Heat-treated, triple-butted Ritchey Logic steel, TIG welded
  • Carbon Ritchey Adventure fork, 1-1/8in straight steerer
  • 700 × 48mm or 650b × 2.0in tyre clearance
  • Flat mount disc, 140mm standard (160mm max with adaptors)
  • 142×12mm rear / 100×12mm front thru-axle
  • Rack and fender mounts front and rear, internal dynamo routing

Compatibility & fit

27.2mm seat tube with integrated seat collar, 68mm English-threaded bottom bracket. Flat mount disc brakes front and rear, rated to 140mm standard (160mm maximum with separate adaptors). 142×12mm rear and 100×12mm front thru-axle spacing. Fork is Ritchey's own carbon Adventure fork with a 1-1/8in straight steerer, 50mm rake/offset and a 390mm fork length. Frame only – groupset, wheels, cockpit, seatpost and saddle are sold separately. The Tune workshop can build this up as a complete bike.

Size & colour

Small frame, Black/Tie Dye colourway.

Ritchey covers this product for two years from the date of purchase against defects in materials and workmanship (the Ritchey International warranty, which covers Australia). Normal wear and tear isn't covered. For warranty support, return the product to Tune Cycles and we'll manage the claim with Ritchey's Australian distributor. This is in addition to your rights under the Australian Consumer Law, so keep your proof of purchase.
  • Triple-butted Ritchey Logic steel frame, TIG welded
  • Carbon Adventure fork, 1-1/8in straight steerer
  • 700×48mm or 650b×2.0in tyre clearance
  • Flat mount disc, 140mm standard (160mm max with adaptors)
  • 142×12 rear / 100×12 front thru-axle
  • Rack, fender and dynamo mounts
BrandRitchey
Frame materialTriple-butted Ritchey Logic steel, TIG welded
SizeSmall
ColourBlack/Tie Dye
ForkRitchey carbon Adventure fork, 1-1/8in straight steerer
Seatpost27.2mm, integrated collar
Bottom bracket68mm English threaded
Rear axle142×12mm thru-axle
Front axle100×12mm thru-axle
Brake mountFlat mount, 140mm standard (160mm max with adaptors)
Tyre clearance700×48mm or 650b×2.0in
MountsRack and fender mounts, internal dynamo routing
SKU DTW-RIG-FRGVOB4SMKTD
Barcode # 796941975223
Brand Ritchey
