A drop handlebar built for mixed-terrain riding — tarmac, gravel and everything between — with a shallower drop and a flare that gives more control in the hooks on rough ground, finished in Ritchey's high-polish Classic silver.

Highlights

  • Double-butted 6061 aluminium, compact bend with an ergonomic top section
  • 118mm drop, 73mm reach
  • 12° drop flare, 3° flare-out, 4° backsweep on the ergo top
  • 31.8mm clamp and accessory-mount diameter
  • Compatible with the Shimano EW-RS910 junction box

Comfort in the hooks

The shallower 118mm drop keeps the hooks accessible and controllable, and the 12° flare — now standard on modern road and gravel bars — adds stability when you're off the hoods on loose surfaces.

Routing

No internal cable routing; cables and hoses run externally along the bar, which also makes this a straightforward bar to fit a Shimano EW-RS910 junction box to.

Options

WidthWeight
38cm—
40cm—
42cmAbout 295g

Compatibility & fit

31.8mm clamp diameter fits any standard 31.8mm stem. Clip-on aero bar compatible. Sold undrilled for a classic (non-integrated) build; no internal routing.

Ritchey covers this product for two years from the date of purchase against defects in materials and workmanship (the Ritchey International warranty, which covers Australia). Normal wear and tear isn't covered. For warranty support, return the product to Tune Cycles and we'll manage the claim with Ritchey's Australian distributor. This is in addition to your rights under the Australian Consumer Law, so keep your proof of purchase.
  • Double-butted 6061 aluminium
  • Compact bend, ergonomic top section
  • 118mm drop, 73mm reach
  • 12° drop flare, 4° backsweep
  • 31.8mm clamp diameter
  • Shimano EW-RS910 junction box compatible
  • High-polish silver finish
MaterialDouble-butted 6061 aluminium
BendCompact, ergonomic top
Drop118mm
Reach73mm
Drop flare12°
Flare out3°
Backsweep4°
Clamp diameter31.8mm
ColourHigh-polish silver
Width (this range)38cm, 40cm, 42cm
SKU DTW-RIG-HBCLBT-PAR
Brand Ritchey
