Profile Design WINGa Alloy Aero Base Bar 44cm Black
SKU code: BCP-RHWA441
The WINGa is the successor to Profile Design's T2 wing, with improved grip ergonomics and cable routing. The formed wing section adds aero, and the routing keeps cables out of the wind. This is the 44 cm width in matte black.
Highlights
- Successor to the T2 wing
- Formed wing section, cables routed out of the wind
- Clamp area widens with bar width: 140 mm on the 44 cm
- 6061-T6 aluminium, 31.8 mm clamp
- Di2 compatible, internally routed brake levers
Wider bar, wider clamp area
The clamping area gets wider as the bar gets wider, so larger riders can run a wider elbow position in the aerobars. The installation manual gives 100, 120, 140 and 160 mm for the 40, 42, 44 and 46 cm bars, so the 44 cm has a 140 mm clamp area.
Compatibility & fit
Clamps a 31.8 mm stem; Profile Design says it can be used with any Profile Design clip-on aerobar, brake lever and stem option. The basebar manual lists the Sonic, Supersonic, Subsonic, Neosonic and Hypersonic brackets, other Profile Design clip-ons with a 31.8 mm basebar clamp, and the Aerobar Bracket Riser Kit (15–70 mm). Only internally routed brake levers fit. Torque: stem clamp 6 Nm, aerobar bracket clamp 6 Nm; overtightening either clamp can crack the bar.
Aerobar fitting and position set-up is a separate workshop service and isn't included in the price. Our workshop can fit it and set up your position.
Profile Design warrants this product to the original retail purchaser against defects in materials and workmanship for two years from the date of original retail purchase. The warranty does not cover products that have been modified, misused, involved in a crash or impact, or damaged by improper assembly or by failing to follow the installation instructions.
This cover is in addition to your rights under the Australian Consumer Law. Keep your proof of purchase.
For warranty support, return the product to Tune Cycles and we'll manage the claim with Profile Design's Australian distributor.
- 44 cm centre to centre, 140 mm clamp area
- Formed wing section for aero
- Routing keeps cables out of the wind
- Internally routed brake levers only, Di2 compatible
- 6061-T6 aluminium, matte black
| Width | 44 cm (centre to centre) |
|---|---|
| Centre clamp diameter | 31.8 mm |
| Clamp width | 140 mm (44 cm size) |
| Material | 6061-T6 aluminium |
| Finish | Matte black |
| Pursuit drop | 0 |
| Pursuit OD / ID | 23.8 / 20.3 mm |
| Brake levers | Internally routed only |
| Di2 | Compatible |
| Weight | 285 g (42 cm, brand-listed) |
| Torque | Stem clamp 6 Nm, aerobar clamp 6 Nm |
| SKU | BCP-RHWA441 |
| Model # | RHWA441 |
| Brand | Profile Design |
| Shipping Weight | 0.4650kg |
| Shipping Width | 0.120m |
| Shipping Height | 0.100m |
| Shipping Length | 0.800m |
