Profile Design Canta Race Carbon Aero Drop Bar 33cm
SKU code: BCP-RHCTAR331
The Canta Race is a carbon aero drop bar built for flatland speed, for riders who want an aggressive aero or TT-style wrist position. A 10° inward angle brings the hoods in for a narrow, UCI-legal hood placement.
Highlights
- 10° inward angle for a narrow hood position
- Deep aero tops extend 90 mm forward, with a large surface to rest your forearms
- More wrist clearance in sprints
- Bar tape ledge for a clean finish
- Internal routing for mechanical or Di2, through the stem or along the outside
Position
The aero tops reach 90 mm forward, adding reach and giving more clearance for your wrists when sprinting, and their large surface area gives your forearms a place to rest while you hold the position. Profile Design lists only the 39 and 42 cm sizes as UCI legal; this 33 cm size isn't on that list.
Cable routing
Ports let you route cables internally through a compatible stem, or through the holes on the edge of the wing if your stem routes externally. Brake and electronic shift cables exit at the hoods.
Compatibility & fit
31.8 mm clamp: Profile Design lists any Profile Design 31.8 mm stem as compatible. Not compatible with clip-on aerobars. Maximum clamping torque 6 Nm; use an assembly compound such as Finish Line Fiber Grip. The bar measures 330 mm at the drops (Width B in Profile Design's drawing) and 290 mm at Width A. Our workshop can fit the bar, route your cables and set up your position.
Profile Design warrants this product to the original retail purchaser against defects in materials and workmanship for two years from the date of original retail purchase. The warranty does not cover products that have been modified, misused, involved in a crash or impact, or damaged by improper assembly or by failing to follow the installation instructions.
This cover is in addition to your rights under the Australian Consumer Law. Keep your proof of purchase.
For warranty support, return the product to Tune Cycles and we'll manage the claim with Profile Design's Australian distributor.
- 33 cm at the drops
- 10° inward hood angle
- 90 mm reach, 130 mm drop, 12 mm drop offset
- Internal routing, mechanical or Di2
- Carbon, matte black
- Not aerobar compatible
| Width | 33 cm (centre to centre / drop measurement) |
|---|---|
| Width A / Width B (manual drawing) | 290 mm / 330 mm |
| Reach | 90 mm |
| Drop | 130 mm |
| Drop offset | 12 mm |
| Clamp diameter | 31.8 mm |
| Aerobar clip-on compatible | No |
| Internal cable routing | Yes (mechanical / Di2) |
| Max clamping torque on bar | 6 Nm |
| UCI legal | Not listed (UCI legal sizes: 39 and 42 cm) |
| Material | Carbon |
| Finish | Matte black |
| SKU | BCP-RHCTAR331 |
| Model # | RHCTAR331 |
| Brand | Profile Design |
| Shipping Weight | 0.4800kg |
| Shipping Width | 0.120m |
| Shipping Height | 0.100m |
| Shipping Length | 0.800m |
