A triple-butted spoke steps down through three diameters rather than one, trimming more weight from the middle while keeping the elbow and thread at full strength — this one runs 2.2mm/2.0mm/1.6mm/2.0mm, J-Bend, in Pillar’s black finish.

Compatibility & fit

Spoke length has to match your exact hub, rim and lacing pattern — the wrong length can’t be fixed once a spoke’s cut. Tune’s wheel-building service calculates the length for your build and can supply and build with it.

Options

Pack sizeLengths available
Pack of 18264mm, 266mm, 268mm, 270mm, 272mm, 274mm, 276mm, 278mm, 280mm, 282mm, 284mm, 286mm, 288mm, 290mm, 292mm, 294mm, 296mm, 298mm, 300mm, 302mm, 304mm, 306mm, 308mm, 310mm

Pillar backs its spokes, nipples and tools against manufacturing defects in materials and workmanship; it doesn’t cover damage from an incorrect spoke length, over-tensioning, crash damage or normal wear. For warranty support, return the product to Tune Cycles and we’ll manage the claim with Pillar’s Australian distributor.

This is in addition to your rights under the Australian Consumer Law — keep your proof of purchase.

  • Triple-butted profile, 2.2mm/2.0mm/1.6mm/2.0mm
  • J-Bend head, Black finish
  • Sold without nipples
BrandPillar
ProfilePSR triple-butted
HeadJ-Bend
Gauge2.2mm/2.0mm/1.6mm/2.0mm
ColourBlack
NippleNot included
SKU DTW-PRG-SJPDB1416K-PAR
Brand Pillar
