Pillar PDB1415 Straight-Pull Double-Butted Spokes – Black – 310mm, Pack of 18
SKU code: DTW-PRG-SSPDB1415K310Q18
Pillar’s PDB1415 is a double-butted straight-pull spoke built to a 14G/15G profile — full 2.0mm gauge at the head and thread, tapering to 1.8mm through the middle to save weight without giving up strength where a spoke actually breaks.
Highlights
- Double-butted profile: 2.0mm (14G) at the ends, 1.8mm (15G) through the body
- Straight-pull head for hubs built around it (no J-bend hook)
- Stainless steel, black finish
- 9.0mm thread length
- Supplied without nipples
- Packed in bags of 18
Why double-butted
Butting removes material from the middle of the spoke, the lowest-stress part of the spoke once it’s built into a wheel, while keeping full gauge at the head and thread where the load actually concentrates. That cuts wheel weight without a strength penalty — standard practice on a quality hand-built wheel.
Compatibility & fit
Spoke length is specific to the hub, rim and lacing pattern of the wheel it’s built into — there’s no generic right answer. The Tune Cycles workshop calculates the correct length for your build and laces the wheel in-house; because these spokes are supplied without nipples, pair them with nipples sized to this spoke’s gauge. A spoke cut or ordered to the wrong length can’t be corrected afterwards.
Options
| Pack size | Lengths available |
|---|---|
| Pack of 18 | 260mm, 262mm, 264mm, 266mm, 268mm, 270mm, 272mm, 274mm, 276mm, 278mm, 280mm, 282mm, 284mm, 286mm, 288mm, 290mm, 292mm, 294mm, 296mm, 298mm, 300mm, 302mm, 304mm, 306mm, 308mm, 310mm |
Pillar backs its spokes, nipples and tools against manufacturing defects in materials and workmanship; it doesn’t cover damage from an incorrect spoke length, over-tensioning, crash damage or normal wear. For warranty support, return the product to Tune Cycles and we’ll manage the claim with Pillar’s Australian distributor.
This is in addition to your rights under the Australian Consumer Law — keep your proof of purchase.
- Double-butted profile: 2.0mm (14G) at the ends, 1.8mm (15G) through the body
- Straight-pull head for hubs built around it (no J-bend hook)
- Stainless steel, black finish
- 9.0mm thread length
- Supplied without nipples
- Packed in bags of 18
| Brand | Pillar |
|---|---|
| Model | PDB1415 |
| Profile | Double-Butted |
| Head type | Straight-Pull |
| Diameter profile | 2.0mm at the ends, 1.8mm through the middle |
| Gauge | 14G/15G |
| Material | Stainless steel |
| Colour | Black |
| Nipples included | No |
| Approx. weight | 5.7g per 260mm spoke (varies with length) |
| Available lengths | 260mm – 310mm |
| Pack sizes | Pack of 18 |
| SKU | DTW-PRG-SSPDB1415K-PAR |
