PFI 6200-2RS C3 Sealed Hub Bearing 10 x 30 x 9 mm — a sealed cartridge hub bearing from PFI, sold individually.

Highlights

  • 10 mm bore × 30 mm outside × 9 mm wide
  • ISO / industry code 6200-2RS C3
  • 2RS, C3 clearance
  • Chrome steel

Details

Cartridge bearings are matched by their dimensions, not by the hub brand: measure the old bearing's bore, outside diameter and width (or read the code stamped on its seal) and pick the same numbers. C3 is a slightly looser internal clearance — the usual choice for bicycle hubs, where the bearing is pressed into an alloy shell.

Fit

Press-fit. Press on the outer race only when fitting — hammering the inner race brinells the bearing. Sold individually; most hubs use two.

PFI bearings are covered against defects in materials and workmanship. Wear from contamination, water ingress, incorrect fitting (pressing on the wrong race) or use in the wrong application isn't covered.

For warranty support, return the item to Tune Cycles with your proof of purchase and we'll manage the claim with the distributor for you. This cover is in addition to your rights under the Australian Consumer Law.

  • 10 mm bore × 30 mm outside × 9 mm wide
  • ISO / industry code 6200-2RS C3
  • 2RS, C3 clearance
  • Chrome steel
Code6200-2RS C3
Bore (ID)10 mm
Outside diameter (OD)30 mm
Width / height9 mm
Seal2RS, C3 clearance
MaterialChrome steel
Sold asEach
BrandPFI
SKU BPW-B03
Model # B03
Barcode # 0739210364335
Brand PFI
