Downhill hammers hubs harder than anything else on the bike. Hope's Pro 5 DH rear hub is built for exactly that: a steel freehub, six pawls that all engage at once and a stiffer axle, set up here for 157x12 downhill frames.

Highlights

  • Steel freehub for maximum strength and durability
  • 54-point engagement with six pawls engaging simultaneously for reliable drive
  • Wire-cut pawls made from high-strength steel
  • Zero-drag labyrinth seal and improved sealing against dirt
  • Fully serviceable and rebuildable with simple tools

Built for downhill

Where the standard Pro 5 chases fast engagement, the DH version prioritises strength: all six pawls share the load at the same time, and the steel freehub body resists damage from hard, repeated torque. Hope specifies the DH hub for 7-speed downhill cassettes, with an XD freehub for single-piece cassettes or an HG freehub for multi-piece cassettes.

Serviceable for years

Like every Hope hub, the Pro 5 DH strips down with simple tools, and its end spacers can be swapped to suit different frame and axle standards. It is a 6-bolt disc hub, drilled 32 hole.

Options

FreehubColours
32 Hole XD DriverBlack, Silver, Red, Blue, Orange, Purple, Bronze
32 Hole Steel Fh (Shimano HG steel)Black, Silver, Red, Blue, Orange, Purple

Compatibility & fit

Suits frames with 157x12 rear spacing and a 6-bolt rotor. Choose the freehub to match your DH cassette. Wheel building is a separate Tune Cycles workshop service – book a workshop appointment.

Hope covers its components for two years from the original date of purchase against manufacturer defects in materials and workmanship. Damage caused by misuse, or by not following the recommendations in the manual, is not covered. For warranty support, return the item to Tune Cycles with your proof of purchase and we'll manage the claim for you. This is in addition to your rights under the Australian Consumer Law.
  • Pro 5 DH rear hub for 157x12 frames
  • Steel freehub body
  • 54-point engagement, six pawls engaging simultaneously
  • Wire-cut high-strength steel pawls
  • Zero-drag labyrinth seal
  • 6-bolt disc mount
  • 32 hole drilling
  • Swappable end spacers
  • Machined in Barnoldswick, England
HubHope Pro 5 DH rear
Axle157 x 12mm
Disc mount6-bolt
Spoke holes32
Engagement54 points, 6 pawls engaging simultaneously
Freehub materialSteel
Cassette7-speed DH (per Hope)
OptionsFreehub: 32 Hole XD Driver, 32 Hole Steel Fh (Shimano HG). Colour: Black, Silver, Red, Blue, Orange, Purple, Bronze (XD only)
SKU BSP-HOPH5R157DH
Brand Hope
Shipping Weight 0.3500kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.220m
