Felt AR Advanced 105 12-Speed Aero Road Bike – Black Charcoal – 54cm
SKU code: APO-FB94024011-54
Clearance item, new in box. Every bike is brand new in its box. These bikes aren’t available to inspect or test ride before you buy. As a run-out bike at a clearance price, we can’t offer a refund or exchange if you change your mind, so please check your size before you buy. This doesn’t affect your rights under the Australian Consumer Law: if the bike has a major fault, you’re still entitled to a repair, replacement or refund.
The Felt AR Advanced aero road race bike with Shimano's 12-speed 105 mechanical groupset: a UHC Advanced carbon AR 3.0 frame, hydraulic disc brakes and an aero handlebar.
- Felt AR 3.0 frame and fork in UHC Advanced carbon
- Shimano 105 R7100 2×12 mechanical groupset, 50/34T crankset and 11-34T cassette
- Shimano BR-R7170 hydraulic disc brakes with 160mm Center Lock rotors
- Devox DBar.C0 aero handlebar, Felt Sprint stem and Felt AeroRoad IL 2.0 seatpost
The details
Devox RDS.A1 wheels (Alex 30mm-deep alloy rims on Shimano RS470 Center Lock hubs, 12mm thru axles) with Continental Grand Sport Race SL 700 × 25c tyres. The compact 50/34T and 11-34T gearing gives a wide range for climbing without giving up the aero frame.
Sizes and finish
Available in Black Charcoal, frame sizes 51cm to 58cm.
Which size?
Felt's size guide for the sizes on this listing:
| Frame size | Rider height | Inseam |
|---|---|---|
| 51cm | 167.6–172.7cm | 75.1–76.2cm |
| 54cm | 172.7–177.8cm | 77.9–82.0cm |
| 56cm | 177.8–182.8cm | 81.0–85.0cm |
| 58cm | 182.8–187.9cm | 84.0–87.1cm |
Between sizes, or not sure? Our team is happy to help you choose.
Delivery and pick-up
Every bike is built and checked by a Tune Cycles mechanic, then delivered ready to ride by Tune Cycles Mobile Mechanic across Sydney, free on bikes over $1,499. Or collect it from our Marrickville workshop. This bike isn't available for courier delivery outside Sydney.
Felt bikes are covered by Felt's limited lifetime warranty on the frameset (and specific Felt components) against defects in materials or workmanship. The cover is for the original purchaser.
- Frameset: limited lifetime, original purchaser
- Branded components (groupset, wheelset, tyres, saddle and other third-party parts): covered by their own manufacturer's warranty
- Register your bike with GPI Apollo, Felt's Australian distributor, after purchase so any claim runs smoothly
The warranty does not cover normal wear and tear (including fatigue), abuse, neglect, accidents, improper repair or maintenance, modification, or use the bike wasn't designed for. For warranty support, return the bike to Tune Cycles with your proof of purchase and we'll inspect it and manage the claim with GPI Apollo for you. This warranty is in addition to your rights under the Australian Consumer Law.
Clearance item: sold new in box, not available for inspection or test ride, and no refunds or exchanges for change of mind. Your rights under the Australian Consumer Law, including a remedy for a major fault, are not affected.
- Felt AR 3.0 frame and fork in UHC Advanced carbon
- Shimano 105 R7100 2×12 mechanical groupset, 50/34T crankset and 11-34T cassette
- Shimano BR-R7170 hydraulic disc brakes with 160mm Center Lock rotors
- Devox DBar.C0 aero handlebar, Felt Sprint stem and Felt AeroRoad IL 2.0 seatpost
| Brand | Felt |
|---|---|
| Model | Felt AR Advanced 105 (12-speed) |
| Colour | Black Charcoal |
| Frame sizes | 51cm, 54cm, 56cm, 58cm |
| Frame | Felt AR 3.0, UHC Advanced carbon |
| Fork | Felt AR 3.0, UHC Advanced carbon |
| Front Brake | Shimano BR-R7170, 2-piston, Hydraulic disc brake |
| Front Brake Rotor | Shimano SM-RT70, 160mm, Center lock |
| Rear Brake | Shimano BR-R7170, 2-piston, Hydraulic disc brake |
| Rear Brake Rotor | Shimano SM-RT70, 160mm, Center lock |
| Brake Lever | Shimano ST-R7120 |
| Rear Derailleur | Shimano 105, RD-R7100, short cage, 24-S |
| Front Derailleur | Shimano 105, FD-R7100, Brazed-On |
| Cassette | Shimano 105 CS-R7100, 11-34T |
| Chain | Shimano CN-HG7100 |
| Crankset | Shimano 105, FC-R7100, 50/34T |
| Shift Lever | Shimano 105, ST-R7120 |
| Wheelset | Devox WheelRDS.A1, Center lock, 12x100/12x142mm, thru axle |
| Front Wheel | Rim: Alex Aluminum 23.8/19/30mm / Hub: Shimano HBRS470CL |
| Rear Wheel | Rim: Alex Aluminum 23.8/19/30mm / Hub: Shimano FHRS470CL |
| Tyre | Continental Grand Sport Race SL, 700x25 |
| Stem | Felt Sprint, -6 ° |
| Headset | IS (NO.44) |
| Handlebar | 48, 51cm: Devox DBar.C0 Aero 31.8mm, 400mm, 54, 56, 58, 61cm: Devox DBar.C0 Aero 31.8mm, 420mm |
| Bar Tape | Felt VelvetGel tape with 3M reflective base and Felt Bubble-Tech F-Wing bar end plugs |
| Saddle | Prologo Dimension 143 STN |
| Seat Post | Felt AeroRoad IL 2.0, 350mm |
| Permissible total weight (rider, bike and gear) | 129kg |
| SKU | APO-P-FELT-AR105-BC |
| Brand | Felt |
| Shipping Weight | 12.0000kg |
| Shipping Width | 0.250m |
| Shipping Height | 0.800m |
| Shipping Length | 1.400m |
