FC-RS400

SHIMANO - Road Crankset - 2x10-speed

This 2-piece crank uses an outboard, 24mm bottom bracket and features 2x10 speed 50-34T compact chainrings.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • MODEL NO: FC-RS400
  • TIAGRA 4600 Series
  • Black color
  • 2-PIECE CRANKSET
  • Chain line: 43.5mm
  • Chainring combination: 50-34T
  • Outboard type Compatible bottom bracket
  • HG-X 10-speed Compatible chain
  • Crank fixing bolt included
  • Crank arm length: 170mm, 175mm
  • 5 arm Spider/Gear
  • Optional Without chain/bash guard
  • 110mm P.C.D.
  • 10 Rear speed
  • Press-fit recommended bottom bracket: BB-RS500-PB
  • Threaded (normal) Recommended bottom bracket: BB-RS500
  • Threaded bottom bracket shell width: 68mm, 70mm
  • Q-factor: 150.3mm
SKU SHM-Y1VM98010
Barcode # 4524667475699
Brand Shimano
Shipping Weight 0.3000kg
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
