FC-RS400

SHIMANO - Road Crankset - 2x10-speed

This 2-piece crank uses an outboard, 24mm bottom bracket and features 2x10 speed 50-34T compact chainrings.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • MODEL NO: FC-RS400
  • TIAGRA 4600 Series
  • Black color
  • 2-PIECE CRANKSET
  • Chain line: 43.5mm
  • Chainring combination: 50-34T
  • Outboard type Compatible bottom bracket
  • HG-X 10-speed Compatible chain
  • Crank fixing bolt included
  • Crank arm length: 170mm, 175mm
  • 5 arm Spider/Gear
  • Optional Without chain/bash guard
  • 110mm P.C.D.
  • 10 Rear speed
  • Press-fit recommended bottom bracket: BB-RS500-PB
  • Threaded (normal) Recommended bottom bracket: BB-RS500
  • Threaded bottom bracket shell width: 68mm, 70mm
  • Q-factor: 150.3mm
SKU SHM-Y1VM98010
Barcode # 4524667475699
Brand Shimano
Shipping Weight 0.3000kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.220m
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
