FC-M7000-11-2

SLX - HOLLOWTECH II - MTB Crankset - 2x11-speed

Perfect for 2x11 MTB drivetrains, the SLX FC-M7000-11-2 crank uses a new 3D composite chainring for improved driving rigidity. It is available with 38-28, 36-26, and 34-24T chainrings.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • Solid pedaling efficiently without loss
  • The new 3D composite chain ring's teeth composition is optimized for each chainwheel load out
  • Balance of strength and lightweight by HOLLOWTECH II crank construction
  • Improved driving rigidity
  • Close-ratio gear combination for minimum shifting gap and maintaining rhythm (FC-M7000-11-2)
  • Enhanced chain retention (FC-M7000-11-1)
  • Better sealing and better rotation
  • MODEL NO: FC-M7000-11-2
  • SLX M7000 Series
  • Series color
  • Average weight: 788.7g (38-28T), 761.4g (36-26T), 739.8g (34-24T)
  • Chain line: 48.8mm
  • Chainring combination: 38-28T 36-26T 34-24T
  • Compatible bottom bracket type_Outboard
  • Compatible chain: HG-X11
  • Crank fixing bolt included
  • Crank arm length (mm)_170
  • Crank arm length (mm)_175
  • Spider/Gear arms: 4
  • HOLLOWTECH II
  • Optional chain guard_Without chain/bash guard
  • P.C.D.: 96/64mm
  • Rear speeds: 11
  • Recommended bottom bracket_Press-fit: BB-MT800-PA
  • Recommended bottom bracket_Threaded (normal): BB-MT800
  • Threaded bottom bracket shell width (mm)_68
  • Threaded bottom bracket shell width (mm)_73
  • Crank arm fixing bolt_With
  • Q-factor: 176mm
  • Chain line: 48.8mm
  • Compatible chain: HG-X11
  • P.C.D.: 96/64mm
  • Rear speeds: 11
  • O.L.D._QR/Nut (mm): 135
  • O.L.D._Thru: 142mm
SKU SHM-Y1VG98020
Barcode # 4524667473312
Brand Shimano
Shipping Weight 1.0890kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.220m
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
