Not every rider wants a deep dish. The Flat Trak gives you a thin, genuinely flat 14mm platform with just 1mm of concave from differing pin heights, so your foot can move and settle where it wants while the pins keep you locked on.

Highlights

• Thin 14mm body with 14mm leading and trailing edges for ground clearance
• 1mm concave profile from differing pin heights, with no bulge over the spindle
• 110 x 105mm functional footprint
• 14 dual-access pins per side with pre-applied Loctite, plus a spare set
• Symmetrical non-offset profile for added foot support and stability
• Load distribution system to help prevent bearing blowout
• Extruded and machined 6061-T6 aluminium with a satin anodised finish and lasered graphics

Flat means flat

Plenty of thin pedals bulge over the spindle and end up more convex than flat. Deity kept the Flat Trak's surface flat from edge to edge, and the low 14mm edges help it clear rocks, roots and low bottom brackets. Deity tested it in real-world riding for two years before release.

Servicing

Deity recommends servicing its pedals at least once a year. The Flat Trak shares its rebuild kit with the Supervillain and its replacement spindle with the Supervillain, TMAC and Bladerunner. Note that the right-hand (drive-side) spindle nut is reverse-threaded. Our workshop can service your pedals as a separate job.

Compatibility & fit

• Designed for downhill, e-bike, enduro, all-mountain and trail riding.
• Fitting is a separate workshop service if you would like us to install them.

Sizes & options
