The HB0050 is a straightforward aluminium drop bar from Canyon, with a 70 mm reach, a 130 mm drop and a 31.8 mm clamp. It's a solid choice when you need a replacement bar or want to change width.

• 31.8 mm clamp: the standard road stem clamp size.
• 70 mm reach, 130 mm drop: a classic road bend.
• Four widths: 400, 420, 440 and 460 mm in silver; 400 mm in black.
• Aluminium: durable and easy to live with.
• Weight: 281 g (400 mm) to 307 g (460 mm).

Choosing a width

Widths step up 20 mm at a time from 400 to 460 mm. If you're changing width, measure your current bar first so you know what you're moving from.

Fit and compatibility

The HB0050 needs a separate stem with a 31.8 mm bar clamp. Canyon doesn't publish a bike list for it, so check your stem's clamp size before ordering, or send us your bike's model and year.

Tune Cycles is an authorised Canyon service partner and can fit and tape your new bar.
