BR-R317

SHIMANO - Post Mount - Mechanical Disc Brake Caliper

With a low profile design, the SHIMANO R317 mechanical disc brake is compatible with post mount framesets and is offered in black and silver.

Shimano warrants to the original retail purchaser that the Shimano bicycle division product for which they received this warranty, is free from non-conformities in material and workmanship for a period of two years and their Dura-Ace and XTR components are covered for a period of three years from the date of original retail purchase. Shimano footwear, soft goods and wheels are warranted for a period of one year.

  • Compact design
  • Lower profile (vs. BR-R505)
  • SM-RT54 160mm recommended
  • Color options: Black, Silver
  • MODEL NO: BR-R317
  • SORA 3500 Series
  • Remarks: SHIMANO logo
  • Compatibility: NEW SUPER SLR
  • Cable: SLR Brake
  • Mount type (available for IS mount with mount adapter): Post mount
  • Brake type: Mechanical disc brake
  • Caliper fixing bolt_Anti loosen method: Snap ring
  • Caliper fixing bolt_Tool size: 5 mm
  • Mount type: Post mount
  • Pad_Standard: G03S Resin
  • Pad mount: Pad axle
  • Piston: 1
  • Recommended brake lever: BL-R2000
  • Recommended disc brake rotor: SM-RT54 (160 mm), SM-RT70 (140 mm)
  • Brake Type: Mechanical disc brake
SKU SHM-EBRR317FURS
Barcode # 4524667490180
Brand Shimano
Shipping Weight 0.3000kg
Shipping Cubic 0.001000000m3
Unit Of Measure each

Must be installed and serviced by qualified bicycle mechanic
