Sold as a single front wheel. This listing is one wheel, not a pair — the matching rear wheel is listed separately.

The DT Swiss AR 1600 SPLINE is the brand’s mid-range aluminium aero road wheel line. This is the front wheel — 30 mm rim depth, in 700C with a 12×100 mm axle, Centre Lock rotor mount.

Fit

  • Rim diameter: 700C
  • Brake type: Disc
  • Rotor mount: Centre Lock
  • Axle: 12×100 mm

Not sure it matches your bike? Send us your frame and drivetrain details and we will confirm before you order.

DT Swiss wheels are covered by DT Swiss's manufacturer warranty against defects in materials and workmanship. Wear from normal use, incorrect installation or crash damage is not covered. Carbon rims may also be eligible for DT Swiss's Fair Share crash-replacement programme — ask us for the current terms. For any warranty claim or support, return the wheel to Tune Cycles and we will handle it with DT Swiss's Australian distributor.

  • One front wheel — sold individually, not as a pair; the matching rear wheel is a separate listing
  • DT Swiss AR 1600 SPLINE: mid-range aluminium aero road wheel line
  • 700C, 12×100 mm, Centre Lock
  • 30 mm rim depth
  • Genuine DT Swiss, supplied through the Australian distributor
Specification Details
Sold asSingle front wheel (one wheel)
Material Aluminum
Rim Joint Sleeve joint
Tire Interface Hooked / Crotchet tubeless TC
Valve Hole Presta
Rim Diameter 29" / 700C
Rim Height 30 mm
Inner Width 20 mm
Outer Width 24 mm
Hub Type 350
Axle System 12 mm Thru Axle
Built-in Dimension 100 mm
Brake Interface Disc Center Lock
Net Weight 1203 g
Recommended System Weight Max 110 kg
ASTM Classification 1
Spoke Pattern Two-cross (1:1)
Nipples DT Pro Lock hidden aluminum
Inclusive Tubeless Tape 23 mm
TL Valve Aluminum black 26-35 mm
SKU APO-DTW-AR16F002
Barcode # 7.61E+12
Brand DT Swiss
