The A3C High Riser Kit raises the armrests and extensions on Profile Design's A3 riser system. Its 40 mm riser is full carbon with an integrated bridge, which Profile Design says halves the weight of the aluminium equivalent.

Highlights

  • Full-carbon 40 mm riser with an integrated bridge
  • Truncated airfoil shape to limit the aerodynamic impact
  • Aluminium 5 mm and 10 mm risers for fine-tuning, up to 60 mm
  • Bolts from 75 mm to 100 mm included to suit each stack height
  • Backwards compatible with the A2 riser system via the A2/A3 adapter

What's in the kit

Risers: four 5 mm aluminium, two 10 mm aluminium and one 40 mm carbon high riser with bridge. Bolts: four each of 75, 80, 85, 90, 95 and 100 mm. Profile Design publishes bolt charts for the A3 bracket and for the A2 bracket with the A3C bridge; use the chart to pick the right bolt for your stack.

Compatibility & fit

Listed by Profile Design for the Wing 20C+ and Wing Ultimate on the A3 riser system. It can be used on the A2 riser system with the A2/A3 adapter, which isn't in the kit.

Aerobar fitting and position set-up is a separate workshop service and isn't included in the price. Our workshop can fit it and set up your position.

Profile Design warrants this product to the original retail purchaser against defects in materials and workmanship for two years from the date of original retail purchase. The warranty does not cover products that have been modified, misused, involved in a crash or impact, or damaged by improper assembly or by failing to follow the installation instructions.

This cover is in addition to your rights under the Australian Consumer Law. Keep your proof of purchase.

For warranty support, return the product to Tune Cycles and we'll manage the claim with Profile Design's Australian distributor.

  • 40 mm full-carbon riser with integrated bridge
  • Four 5 mm and two 10 mm aluminium risers
  • Maximum height 60 mm
  • Bolts 75–100 mm in 5 mm steps, four of each
  • 56 g (risers only, brand-listed)
CompatibilityWing 20C+, Wing Ultimate (A3 riser system); A2 with A2/A3 adapter
Maximum height60 mm
Risers included4 × 5 mm aluminium, 2 × 10 mm aluminium, 1 × 40 mm carbon high riser with bridge
Bolts included4 each of 75, 80, 85, 90, 95 and 100 mm
Weight (brand-listed)56 g (risers only)
SKU BCP-ACA3CHRSKT
Model # ACA3CHRSKT
Barcode #
Brand Profile Design
Shipping Weight 0.4800kg
Shipping Width 0.120m
Shipping Height 0.100m
Shipping Length 0.800m
