A simple, light forged stem that runs in the negative or positive position for -7° or +7° of rise, with a 4-bolt faceplate for stiffness. This is the 100 mm length in black.

Highlights

  • Flip for -7° or +7°
  • 3D-forged 6061-T6 aluminium
  • 4-bolt faceplate for stiffness
  • 31.8 mm bar clamp, 1-1/8 in steerer, 40 mm stack

Compatibility & fit

Fits a 1-1/8 in steerer and a 31.8 mm bar. Profile Design's instructions: two rear M5 steerer bolts (4 mm hex) to 6 Nm, the four faceplate bolts to 5 Nm, tightened evenly. Take particular care with carbon steerers and carbon bars and follow the fork and bar maker's instructions. Profile Design lists 83° (±7°) as the stem angle. The HSF Aeria Faceplate fits the 1/Seventeen only, not this stem.

Our workshop can fit the stem and set your bar height and position.

Profile Design warrants this product to the original retail purchaser against defects in materials and workmanship for two years from the date of original retail purchase. The warranty does not cover products that have been modified, misused, involved in a crash or impact, or damaged by improper assembly or by failing to follow the installation instructions.

This cover is in addition to your rights under the Australian Consumer Law. Keep your proof of purchase.

For warranty support, return the product to Tune Cycles and we'll manage the claim with Profile Design's Australian distributor.

  • 100 mm length, ±7° rise
  • 3D-forged 6061-T6 aluminium, black
  • 4-bolt faceplate
  • 31.8 mm bar clamp, 40 mm clamp width
  • 1-1/8 in steerer, 40 mm stack height
  • Faceplate 5 Nm, steerer bolts 6 Nm
Length100 mm
Angle83° (±7°)
Material3D-forged 6061-T6 aluminium
Bar clamp diameter31.8 mm
Clamp width40 mm
Steerer diameter1-1/8 in
Stack height40 mm
Faceplate4-bolt, 5 Nm
Steerer bolts2 × M5, 6 Nm
ColourBlack
Weight167 g (100 mm, brand-listed)
SKU BCP-RS107071081-1
Model # RS107071081-1
Barcode # 0723660006426
Brand Profile Design
Shipping Weight 0.2670kg
Shipping Width 0.160m
Shipping Height 0.060m
Shipping Length 0.220m
