SRAM GX Eagle E-MTB Crank Arm Assembly - 165mm ISIS Black
006.118.664.001
SKU code: PSI-SR006118664001
In Stock
Bring proven SRAM Eagle durability to your e-MTB with the GX Eagle E-MTB crank arm assembly, forged from aluminium and tuned for the loads of pedal-assist riding. This is the 165mm length — a popular middle option that suits many riders and works well with shorter-travel and mid-power e-MTB setups.
Highlights
- 165mm crank arms, forged aluminium for e-bike durability
- ISIS spindle interface to suit compatible e-bike motor spindles
- Self-extracting crank bolt for easy fitting and removal
- Accepts T-Type Eagle Transmission direct-mount chainrings (sold separately)
- Clean black finish that integrates with the motor housing
Built for pedal assist
The GX Eagle E-MTB crank is optimised for the higher torque and constant drive of a pedal-assist system. The forged aluminium arms deliver robust, dependable power transfer ride after ride, while the dedicated e-bike fitment keeps the Q-factor in check for a natural pedalling feel.
ISIS interface and self-extracting bolt
The arms mount to a compatible ISIS spindle and use a self-extracting crank bolt, so removal and installation are straightforward without a separate crank puller. This makes motor and bottom bracket servicing far simpler.
Compatibility and fit
Designed for e-bikes running an ISIS spindle interface (SRAM/Brose and Bosch e-bike systems). Accepts SRAM T-Type Eagle Transmission direct-mount chainrings. Supplied as crank arms only — the chainring, bottom bracket and crank cap/gap cap are not included and should be selected to match your motor and drivetrain. If you are unsure which spindle or chainring your e-bike uses, contact Tune Cycles before ordering.
SRAM warrants this product to be free from defects in materials and workmanship for two years from the original date of purchase, in line with SRAM's standard warranty terms. The warranty covers manufacturing defects and does not cover damage from crashes, misuse, neglect, improper installation, or normal wear and tear.
For any warranty claim or support, please return the item to Tune Cycles and we will assist you directly — do not contact the brand or distributor.
- SRAM GX Eagle E-MTB crank arm assembly (FC-GX-PA-D1)
- 165mm crank arm length
- Forged aluminium construction
- ISIS spindle interface
- Self-extracting crank bolt
- Compatible with T-Type Eagle Transmission direct-mount chainrings (sold separately)
- Optimised for pedal-assist e-MTB use
- Black finish
- Crank cap/gap cap, chainring and bottom bracket not included
| Brand | SRAM |
| Model | GX Eagle E-MTB |
| Part code | FC-GX-PA-D1 |
| Type | E-bike crank arm assembly (arms only) |
| Crank length | 165mm |
| Material | Forged aluminium |
| Spindle interface | ISIS |
| Crank bolt | Self-extracting |
| Chainring mount | T-Type direct mount (chainring sold separately) |
| Application | Pedal-assist e-MTB |
| Colour | Black |
| Not included | Crank cap/gap cap, chainring, bottom bracket |
| SKU | PSI-SR006118664001 |
| Model # | 006.118.664.001 |
| Barcode # | 710845887093 |
| Brand | SRAM |
