The Prowheel Charm FD099A is a square-taper 1× MTB crankset with a 7075 alloy narrow-wide ring and Boost chainline, for square-taper frames running 9 to 11-speed drivetrains.

Highlights

  • 175 mm crank arms
  • 32T chainring
  • Forged AL-6061-T6, black sand anodised arms
  • Narrow-wide AL-7075-T6, 104 BCD
  • 10/11-speed compatible
  • Square-taper — uses a 113 mm square-taper bottom bracket (not included)

Prowheel

Prowheel is a Taiwanese crank maker that supplies many bike brands as original equipment; these are the same forged cranks sold as aftermarket replacements.

Fit and compatibility

Square-taper — uses a 113 mm square-taper bottom bracket (not included). Match the speed count to your chain and cassette; a 1× narrow-wide ring works with a clutch rear derailleur.

Prowheel products supplied by Tune Cycles are covered against defects in materials and workmanship under the manufacturer's warranty, handled in Australia through the distributor. Normal wear and tear, crash or impact damage, incorrect installation, modification and misuse aren't covered.

For warranty support, return the item to Tune Cycles with your proof of purchase and we'll manage the claim with the distributor for you. This cover is in addition to your rights under the Australian Consumer Law.

  • 175 mm crank arms
  • 32T chainring
  • Forged AL-6061-T6, black sand anodised arms
  • Narrow-wide AL-7075-T6, 104 BCD
  • 10/11-speed compatible
  • Square-taper — uses a 113 mm square-taper bottom bracket (not included)
BrandProwheel
ModelCharm FD099A
Type1× MTB, square taper (Boost)
Crank length175 mm
Chainrings32T
BCD104 mm
Speeds10/11-speed
Axle / interfaceSquare taper
Bottom bracketSquare-taper — uses a 113 mm square-taper bottom bracket (not included)
ChainlineBoost
BoostBoost (148 mm)
Q-factor175 mm
Arm materialForged AL-6061-T6, black sand anodised
Chainring materialNarrow-wide AL-7075-T6, 104 BCD
SKU KWT-PRW-CHARM-FD099A-B32T
Barcode # 743966283390
Brand Prowheel
