Profile Design Race-H Armrest Kit
SKU code: BCP-ACRHKT1
The Race-H has the same curvature as the Race+ with a higher outer wall, which helps you hold a narrow elbow position. The cup sides and pad present a smooth surface for air to flow past the edges.
Highlights
- Higher outer wall for narrow elbow positions
- 124 mm long cup, 87 mm wide, 60 mm high
- Bolt spacing options: 12.5, 14, 16.5, 18.5 and 29 mm
- Race-H Ultra 10–5 mm EVA pads
- Includes an M5 compatibility washer
Fit adjustment
Reach adjusts in 15 mm increments and width in 18.5 mm increments. Stack is 4 mm.
Compatibility & fit
Profile Design says the Race-H can be paired with any of its current and recent model aerobars as a comfort upgrade, and the range of bolt spacings widens the number of bars it fits. The kit includes Profile Design's armrest compatibility washer (M5) for aerobars that use M5 bolts. Hardware is M6 x 12 mm FHB.
Aerobar fitting and position set-up is a separate workshop service and isn't included in the price. Our workshop can fit it and set up your position.
Profile Design warrants this product to the original retail purchaser against defects in materials and workmanship for two years from the date of original retail purchase. The warranty does not cover products that have been modified, misused, involved in a crash or impact, or damaged by improper assembly or by failing to follow the installation instructions.
This cover is in addition to your rights under the Australian Consumer Law. Keep your proof of purchase.
For warranty support, return the product to Tune Cycles and we'll manage the claim with Profile Design's Australian distributor.
- Race+ curvature with a higher outer wall
- Five bolt spacings, 12.5–29 mm
- Reach 15 mm and width 18.5 mm increments
- EVA pads (Race-H Ultra 10–5 mm)
- M5 compatibility washer included
- 233 g per pair
| Length | 124 mm |
|---|---|
| Width | 87 mm |
| Height | 60 mm |
| Stack | 4 mm |
| Bolt spacing | 12.5, 14, 16.5, 18.5, 29 mm |
| Reach increment | 15 mm |
| Width increment | 18.5 mm |
| Armrest | Injected nylon/glass fibre |
| Pads | EVA foam, Race-H Ultra 10–5 mm |
| Hardware | M6 x 12 mm FHB; M5 compatibility washer |
| Colour | Matte black |
| Weight (brand-listed) | 233 g pair |
| SKU | BCP-ACRHKT1 |
| Model # | ACRHKT1 |
| Brand | Profile Design |
| Shipping Weight | 0.3500kg |
| Shipping Width | 0.120m |
| Shipping Height | 0.100m |
| Shipping Length | 0.800m |
