Magicshine EVO 1700 UT Di2 & ANT+ Under-Mount Front Light 1700 Lumen – Titanium
SKU code: KWT-MS-EVO1700UTTITAN
$199.95
EVO 1700 UT is Magicshine's flagship road light, built to work as part of your bike's electronics: control it from a bike computer over ANT+, from your Shimano Di2 shift buttons, or in sync with your rear light through FTR LightSync.
Highlights
- ANT+ connectivity for light control and status on compatible bike computers
- Shimano Di2 control from the shift levers
- FTR LightSync with compatible rear lights (MJ-6558 remote sold separately)
- 1700 lm high beam reaching up to 206 m, plus a wide cut-off low beam
- Dual 18500 cells (5200 mAh): up to 17 h, USB-C charge in about 3 h
- MagicLock magnetic mount, IPX6, smart lockout, app control with OTA updates
Modes and run times
| Beam | Mode | Output | Run time |
|---|---|---|---|
| Low beam | Low | 200 lm | 17 h |
| Low beam | Medium | 400 lm | 9 h |
| Low beam | High | 800 lm | 5 h |
| High beam | Low | 400 lm | 10 h |
| High beam | Medium | 800 lm | 5 h |
| High beam | High | 1700 lm | 3 h |
| Flash | Day flash | 0–1700 lm | 10 h 30 min |
| Flash | Night flash | 400–1700 lm | 6 h |
Optics
A large blue-coated lens improves light transmission, and side visibility helps at intersections.
Compatibility & fit
The MagicLock mount supports standard and under-bar set-ups and integrates with Garmin and Wahoo mounting systems. Magicshine's box list for the UT is the light, a USB-C cable and the user manual, so check you have a compatible mount, or ask us which out-front mount suits your bars.
Magicshine lists a 2-year warranty for the EVO 1700 UT. For warranty support, return the product to Tune Cycles and we'll manage the claim with KWT Imports, Magicshine's Australian distributor.
- ANT+ connectivity
- Shimano Di2 control
- FTR LightSync
- 1700 lm high beam, cut-off low beam
- Up to 17 h, USB-C charging
- MagicLock magnetic mount, IPX6
| Max output | 1700 lumens |
|---|---|
| Run time | Up to 17 h |
| Beam pattern | High beam + low beam |
| Connectivity | ANT+, Shimano Di2, FTR LightSync |
| Battery | 3.6V, 5200 mAh (2 x 18500) |
| Charging | USB-C, 3 h (5V 2A) |
| Body | Aluminium alloy + plastic |
| Mounting | MagicLock magnetic |
| Waterproof rating | IPX6 |
| Dimensions | 44 x 51 x 57 mm |
| Weight | 175 g |
| Colour | Titanium |
| SKU | KWT-MS-EVO1700UTTITAN |
| Brand | MAGICSHINE |
| Shipping Weight | 0.2000kg |
| Shipping Width | 0.100m |
| Shipping Height | 0.060m |
| Shipping Length | 0.150m |
