The DT Swiss 240 is the brand's benchmark performance hub, and this Silver rear version is built for Boost mountain bike wheels running Shimano 12-speed drivetrains.

Highlights

  • Silver colourway
  • Rear hub for Boost 148mm frames
  • 12/148mm thru-axle, 6-bolt disc mount
  • Shimano Micro Spline driver for 12-speed drivetrains
  • 32-hole spoke interface
  • DEG 90-tooth ratchet for 4-degree engagement
  • e-bike approved (max. 32 km/h / 250 W)

Ratchet EXP

The 240 runs the DT Swiss Ratchet EXP system. This rear hub is fitted with the DEG 90-tooth ratchet, dropping engagement to just 4 degrees for near-instant pickup on technical climbs and punchy trail efforts. Both ratchet rings stay in mesh under load for proven durability.

Compatibility & fit

Suits Boost 148mm rear spacing with a 12mm thru-axle and 6-bolt disc rotors. The Shimano Micro Spline driver fits Shimano 12-speed Micro Spline cassettes. Designed for 32-hole wheel builds.

DT Swiss covers this hub with a 24-month warranty against material and manufacturing defects from the date of purchase. Normal wear items, including bearings and freehub bodies, are not covered. The DT Swiss crash-replacement (Fair Share) programme applies to carbon rims only and does not apply to this product.

For any warranty support, please return the item to Tune Cycles and our team will handle the claim on your behalf.

  • DT Swiss 240 Silver rear hub
  • Boost 12/148mm thru-axle
  • 6-bolt disc brake mount
  • Shimano Micro Spline driver body
  • 32-hole flanges
  • DEG 90-tooth ratchet, 4-degree engagement
  • Steel cartridge bearings
  • e-bike approved (max. 32 km/h / 250 W)
Brand DT Swiss
Model 240
Position Rear
Discipline MTB
Brake interface 6-bolt
Axle Boost 12/148mm thru-axle
Hole count 32H
Spoke type Standard J-bend / straight-pull (build dependent)
Freehub body Shimano Micro Spline (12-speed)
Engagement DEG 90-tooth ratchet, 4 degrees
Bearings Steel cartridge bearings
E-bike approved Yes (max. 32 km/h / 250 W)
Colour Silver
SKU APO-DTH2410_LTD_ED_A
