A DT Swiss 12 x 142 mm thru axle with a 1.0 mm thread pitch, listed by Canyon for several of its 2027 road, gravel and triathlon frames.

  • Size: 12 x 142 mm.
  • 1.0 mm thread pitch: the pitch has to match the thread in the frame.
  • Light: 35 g.

Getting the right axle

Thru axles differ in diameter, length and thread pitch, and a near match won't do. Your frame code or the part number is the reliable check.

Fit and compatibility

Canyon lists this axle for:

  • Aeroad: CFR Disc and CFR 2027 (R136-01)
  • Endurace: CFR 2027 (R148-01)
  • Grail: CFR 2027 (R141-01)
  • Speedmax: CF 2027 (R133-01); CF and CFR 2027 (R134-01)

Match your frame code and model year to this list before ordering, or send us your bike's details and we'll confirm.

Need it fitted? Tune Cycles is an authorised Canyon service partner.

DT Swiss warranty. Covered against manufacturing defects under DT Swiss's warranty terms; ask us for the period that applies. For warranty support, return the item to Tune Cycles with your proof of purchase and we'll manage the claim for you. This is in addition to your rights under the Australian Consumer Law.

  • DT Swiss thru axle
  • Size: 12 x 142 mm
  • Thread pitch: 1.0 mm
  • Weight: 35 g
BrandDT Swiss
Size12 x 142 mm
Thread pitch1.0 mm
Weight35 g
Frame codesR133-01, R134-01, R136-01, R141-01, R148-01
