Genuine Canyon GP0172-01 Derailleur Hanger. The hanger is the small replaceable bracket the derailleur bolts to. It's made to bend or break before the frame does, so a crash or a knock in transit usually costs a hanger, not a frame. A bent hanger is the most common cause of poor shifting after a fall.

What's in the box

• 1x Canyon EP0787-01 Derailleur Hanger with screw

Fits

Canyon lists this part for:

• 2019: Sender AL (M047) / Sender CF (M34) / Dude CF (M045)
• 2018: Neuron AL (M13) / Sender AL (M047) / Sender CF (M34) / Strive CF Hybrid (M072) / Strive AL (M24) / Strive CF (M27) / Dude CF (M045)
• 2017: Neuron AL (M13) / Strive AL (M24) / Strive CF (M27) / Sender CF (M34)
• 2016: Torque FRX (M20) / Neuron AL (M13) / Spectral AL (M17) / Sender CF (M34) / Strive AL (M24) / Strive CF (M27) / Grand Canyon CF 29 (M042)
• 2015: Torque FRX (M20) / Nerve AL (M13) / Spectral AL (M17) / Strive AL (M24) / Strive CF (M27) / Grand Canyon CF 29 (M042)
• 2014: Torque FRX (M20) / Nerve AL (M13) / Spectral AL (M17)

Before you order

Canyon spares are matched to the frame code and model year. Check your bike against the list above. Not sure? Send us the model, year and frame size, or the frame's serial number, and we'll confirm the part before it's ordered.

Fitting

Tune Cycles is an authorised Canyon service and assembly partner, so we can fit this part for you at the workshop or with our mobile service.
